- Highly integrated SoC, comprising of RF, analog, baseband, MCU, SRAM, flash and peripherals
- Frequency range from 4.0GHz to 9.0GHz, supports UWB channel number 3, 5, 6, 8, 9 and 10
- Supports 1 Tx antenna and maximum of 4 Rx antennas for 3D AoA positioning applications
- Supports 850Kbps, 6.8Mbps, 7.8Mbps, 27.2Mbps and 31.2Mbps
- Supports the base pulse repetition frequency (BPRF) mode with 64MHz peak PRF and higher pulse repetition frequency (HPRF) mode with 124.8MHz and 249.6MHz peak PRF
- ARM Cortex 32bit processor with the clock up to 124.8MHz
- 384KB RAM and 512KB flash
- SPI/UART/I2C/GPIO peripheral interfaces
- SPI interface with the clock up to 40MHz
- Integrated AES-128/256 for secure ranging
- Transmit Power: −18 dBm to 10 dBm
- Receiver sensitivity: -93dBm @6.8Mbps and -101dBm @850Kbps
- TX peak power consumption: 68.4mW*
- (1.2V*54mA=64.8mW; 2.1V*1.71mA=3.6mW)
- RX peak power consumption: 121mW
- (1.2V*97.5mA=117mW; 2.1V*1.88mA=4mW)
- 1.3uA deep sleep mode current
- Dual power supply voltage: VDD1: 2.1V to 3.3V, VDD2: 1.15V to 1.8V
